STM32L476VET6 is an ultra-low power ARM Cortex-M4 microcontroller launched by STMicroelectronics (ST), featuring low power consumption and rich peripherals, suitable for battery powered devices.

core performance

Processor core: 32-bit ARM Cortex-M4 with floating point unit (FPU), maximum clock speed of 80 MHz, performance of approximately 100 DMIPS.

Storage capacity: Built in 512 KB Flash program memory and 128 KB SRAM, supporting dual storage area architecture for simultaneous read and write operations.

Working voltage: 1.71V to 3.6V, supporting a wide temperature range (-40 ° C to+85 ° C or higher).

Packaging form: LQFP-100 (100 pins, 14x14mm), with approximately 82 I/O units. ‌‌‌

What are the characteristics of low power consumption

Multiple low-power modes: supports seven modes: run, sleep, low-power run, stop 0/1/2, standby, and shutdown.

Typical power consumption data:

VBAT mode (only RTC and backup register work): approximately 300nA.

Standby mode: approximately 120nA (approximately 420nA with RTC).

Shutdown mode: approximately 30nA.

Operation mode: LDO mode is about 100 μ A/MHz, and SMPS mode can be reduced to about 39 μ A/MHz.

Fast wake-up speed: It only takes about 4 μ s to wake up from stop mode and supports batch acquisition mode (BAM). ‌‌‌
