SCA3401-D01 | Murata (industrial-grade three-axis digital MEMS accelerometer | non-automotive grade)

SCA3401-D01

Model interpretation

SCA3401: Series model, three-axis accelerometer

D01: Version code, digital SPI output, standard industrial version

Core electrical parameters

form

project

parameter

Measurement axis

X/Y/Z three-axis synchronous acquisition

Measuring range (software can be selected from two options)

Mode 1: ±1.2g, 10Hz low-pass filter (static tilt) Mode 2: ±2.4g, 80Hz low-pass filtered (dynamic vibration)

sensitivity

15000 LSB/g

Noise density

20 μg/√ Hz (ultra-low noise) Murata Man...

Zero-point drift of the life cycle

X/Y ≤ 0.5mg, Z ≤ 2mg, long-term calibration-free electronic engineering world...

Temperature drift -40 ~ + 85 ℃

X/Y≤2mg，Z≤3mg

Power supply voltage

3.0-3.6V, typical 3.3V main control adapter

Communication interface

Safe‑SPI 2.0, maximum ODR 20,000Hz

Operating temperature

‑40℃ ~ +85℃Mouser Ele...

Self-diagnosis

Built-in MEMS, ASIC, short-circuit fault self-check function

to encapsulate

12-PIN DFL surface mount package

Body size

8.6 × 7.6 × 3.3 mmMurata Man...

MPQ

Pallet packaging

Appearance form

Black plastic-coated square metal cover plate sticker module, metal cover plate printing model and Murata logo; Side gold plated pins, 12-pin SMT reflow soldering; The thickness of the module is 3.3 mm, which belongs to the thick packaging of industrial inertial sensors. It cannot be washed and needs to control the reflux temperature curve when soldering. It is made by Murata Manufacturing Co., Ltd.

Typical applications

Structural Health Monitoring SHM: Bridge, Building, Micro Deformation, Inclination Monitoring Electronic Engineering World...

High precision inclination, platform leveling, horizontal measurement

IMU (Inertial Measurement Unit), construction machinery, surveying tools

Equipment vibration monitoring and predictive maintenance system
