APXG160ARA680MF46G | NCC Chemi‑Con | PXG Series SMD Conductive Polymer Solid Aluminum Electrolytic Capacitor

Electrical Specifications

Rated Voltage: 16V DC

Capacitance: 68μF

Capacitance Tolerance: ±20% (Grade M)

Max. ESR: 40mΩ (20℃, 100‑300kHz)

Rated Ripple Current: 2450mA @105℃, 100kHz

Dimensions: Φ6.3mm × 4.5mm (Height)

Operating Temperature: ‑55℃ ~ +105℃

Service Life: 3000 hours @105℃

Max. Leakage Current: 544μA (20℃ / 2 minutes)

Package: SMD surface‑mount, tape & reel packaging, halogen‑free, RoHS2 compliant, wash‑resistant

Non‑automotive grade (No AEC‑Q200 qualification)

Functions

Power input filtering: Absorb high‑frequency ripple, suppress power‑supply noise and stabilize DC voltage.

High ripple current capability: Polymer electrolyte with ultra‑low ESR, ideal for switch‑mode power supply output circuits.

Fast charge‑discharge: Excellent high‑frequency response to minimize voltage drop.

Anti‑interference: Absorb voltage spike pulses, protect downstream ICs and reduce digital‑circuit interference.

Comparison with conventional liquid aluminum electrolytic capacitors: Much lower ESR, superior high‑frequency performance, no electrolyte swelling or leakage. Polarized component; observe polarity during soldering.

Applications

Input / output filtering for USB‑PD fast‑charging boards, Type‑C power boards and DC‑DC power modules

Industrial mainboards, PC peripherals and industrial control boards

Power circuits for network devices including routers, switches and set‑top boxes

Industrial embedded systems, UAV power boards and security equipment power loops

Power circuits within 16V rating for high‑ripple and high‑frequency filtering scenarios
