GEN600‑5.5 is a 2U rack‑mount high‑power programmable DC power supply from TDK‑Lambda Genesys series.

GEN600‑5.5 is a 2U rack‑mount high‑power programmable DC power supply from the TDK‑Lambda Genesys series. It features single‑channel high‑voltage DC output with a rated power of 3300 W. It supports automatic crossover between Constant Voltage (CV) and Constant Current (CC) modes, local front‑panel operation as well as digital remote programming. It can be either rack‑mounted or used as a bench‑top unit for high‑voltage power supply and component testing in laboratories and production lines.

Key Specifications

Output

Output voltage: 0‑600 VDC continuously adjustableOutput current: 0‑5.5 A continuously adjustableRated power: 3300 WOperating mode: Automatic crossover of Constant Voltage (CV) / Constant Current (CC)Ripple & noise: Voltage ≤120 mVrms; Current ≈20 mA rmsEfficiency: 87% typical

Input (two variants)

1P230 (single‑phase): AC 170‑265 V, 47‑63 Hz3P400 (three‑phase): AC 342‑460 V, 47‑63 Hz

Communication and Control

Standard: RS‑232, RS‑485 serial communicationOptional upgrades: LAN (LXI), USB, GPIB, isolated analog control interfaceSupports analog programming, master‑slave parallel operation for power expansion, front‑panel lockout and parameter memory.

Protection Functions

Over‑Voltage Protection (OVP), Over‑Current Protection (OCP), Over‑Temperature Protection (OTP), short‑circuit protection and remote inhibit function.

Mechanical and Environmental

Form factor: 2U 19‑inch rack unit; dimensions 423 × 88 × 442.5 mm; weight approx. 13 kgOperating temperature: 0 ℃ ~ +50 ℃Safety certifications: UL/EN/IEC 61010‑1, CE, UKCA

Applications

Semiconductor and Power‑Device TestingBurn‑in and reliability testing for high‑voltage MOSFET, IGBT and GaN devices; durability burn‑in testing for high‑voltage capacitors and resistors.

New‑Energy IndustrySimulated power supply and charge‑discharge simulation testing for high‑voltage energy‑storage modules, PV assemblies and high‑voltage battery packs.

Industrial‑Automation Production LinesProgrammable high‑voltage DC power supply for automated burn‑in stations and ATE test equipment; power‑supply simulation for industrial‑control hardware.

Laboratory ResearchHigh‑voltage DC power supply for experiments; R&D testing for materials and high‑voltage components.

OthersSimulated power‑supply testing for aerospace components and automotive high‑voltage parts. Multiple units can be operated in master‑slave parallel configuration to build higher‑power systems.
