VND7040AJTR, Automotive‑Grade Dual‑Channel Smart High‑Side Driver, STMicroelectronics
| Item | Parameters |
|---|---|
| Model | VND7040AJTR |
| Number of Channels | 2 channels with independent control |
| Load Voltage | 4V‑28V (for 12V automotive systems), 40V transient withstand voltage |
| On‑state Resistance Rds(on) per Channel | Typ. 40 mΩ @ 25℃ |
| Continuous Output Current per Channel | Max. 24A; typical current‑limit 34A |
| Logic Input | 3V / 5V CMOS‑compatible |
| Package | PowerSSO‑16 (SMD) |
| Standby Current | Max. 0.5 μA |
| Diagnostic Functions | MultiSense multiplexed analog output: load‑current sensing, supply voltage, chip temperature; open‑load detection, short‑to‑ground detection, short‑to‑supply detection |
| Protection Functions | Current limiting, power limitation, thermal shutdown (configurable latch‑off / auto‑restart), UVLO under‑voltage lockout, over‑voltage clamping, loss‑of‑ground protection; FaultRST fault reset pin |
| Automotive Qualification | AEC‑Q100 |
| Junction Temperature Range | -40℃ ~ +150℃ |
| Packaging | Tape & Reel |
## Application Scope
✅ **Automotive Electronics (Primary Market)**
1. BCM Body Control Module: automotive rear lamps, brake lamps, turn‑signal lamps, LED combination rear lamps, halogen lamp loads
2. Solenoid and relay coil driving (inductive loads)
3. Small DC motor driving: door locks, rear‑view mirrors, window actuators
4. Automotive ground‑referenced loads requiring current monitoring and fault diagnosis
✅ **Industrial (Use caution for non‑automotive applications)**
12V‑24V industrial equipment requiring high‑side switch with current sensing and fault reporting; load switches and solenoid drivers for industrial control boards.
⚠️ Notes
1. Designed for **ground‑referenced loads**. Energy dissipation shall be considered for inductive loads; refer to the datasheet for ground‑loop protection circuits.
2. AEC‑Q100 qualified; prioritized for automotive customers. Cost‑inefficient for general consumer products.
3. The MultiSense function converts current and temperature into analog voltages for ADC input, eliminating external sense resistors.
