The SCH16T-K10 is a high-dynamic-range 6-axis IMU (three-axis gyroscope + three-axis accelerometer) in the SCH16T series, based on the mature capacitive 3D-MEMS process. It focuses on ultra-large angular velocity range, industrial-grade stability, built-in self-diagnosis, and synchronous acquisition capability, and is aimed at large dynamic scenes such as high-speed drones, motion robots, and construction machinery attitude perception, solving the problem of sensor output saturation under high-speed rotation.

I. Basic specifications and package appearance information

Brand model: Murata (Murata) SCH16T-K10

Sensor type: 6-axis IMU, 3-axis gyroscope + 3-axis accelerometer

Package: pre-formed reinforced SOIC-24 surface mount package, size 12mm × 14mm × 3mm, 24-pin double-sided gold-plated solder pads, SMT surface mount, cannot be directly inserted.

Power supply: 3.0V-3.6V, typical 3.3V industrial MCU system power supply

Operating temperature: ‑40°C ~ +110°C, ultra-wide industrial temperature range, compatible with vehicle and outdoor high-temperature equipment Murata Man...。

Gyro range: Nominal ± 2000° / s, dynamic can withstand up to ± 2600° / s;The software can be downgraded to use ±100°/s.

Acceleration measurement range: nominal ±16g, auxiliary channel maximum dynamic ±26g Murata Man...。

Output precision: supports two digital output modes of 16bit/20bit, flexibly balancing speed and resolution.

Packaging Compliance: Roll T&R packaging; Meets RoHS and ELV environmental regulations.

Appearance recognition: black reinforced plastic casing, surface engraved model SCH16T-K10, Murata CM logo and QR code; Each side has 12 gold-plated pins, the mechanical structure of the shell is strengthened, and it is resistant to impact and vibration. It is different from the ordinary consumer-level small-sized QFN sensor Murata Man....。

2. Internal hardware architecture

The SCH16T-K10 uses a MEMS sensitive unit + ASIC dedicated signal processing chip integrated packaging scheme:

The three-axis gyroscope and three-axis accelerometer of the 3D-MEMS sensing unit are all capacitive MEMS structures, the mechanical structure is reinforced, the inter-axis orthogonal compensation is completed at the factory, which reduces the calibration workload of the customer's production line, reduces the production calibration cost, and is suitable for mass industrial production.

The mixed-signal ASIC processing unit integrates signal amplification, AD conversion, multi-stage digital filtering, extraction/interpolation output, temperature acquisition, and fault self-diagnostic logic. The built-in on-chip temperature sensor can read the temperature inside the chip, which is convenient for the main control software to make temperature drift compensation.

SafeSPI2.0 digital interface unit dedicated industrial SPI protocol, with communication check, suppress industrial environment bus interference; Integrated SYNC synchronization input, data ready DRDY, timestamp index, supports multi-IMU time synchronization acquisition, suitable for distributed multi-node attitude system.

The fault monitoring module real-time monitors the MEMS structure, power supply, registers, and signal paths at the hardware level, and the fault status is stored in the register for the master to read.

III. Core performance indicators

Gyroscope (angular velocity)

Bias instability: 2 °/h, ensuring zero-point stability of attitude calculation for a long time Murata Man...

Noise density: 6 m°/s / √Hz, good noise level at high range

Angle random walk: 0.26°/√ h

Bandwidth software optional: 13Hz, 30Hz, 68Hz, 235Hz, 280Hz, 370Hz multi-stage configurable, filter noise reduction and high-speed dynamic response Murata Man...

Accelerometer

Nominal range: ±16g, auxiliary channel dynamic range: ±26g, suitable for severe impact and overload scenarios

The output stability of the full temperature range is excellent, the anti-vibration correction mechanism reduces the measurement error caused by mechanical vibration.

Comparison with the same series: SCH16T-K01/K02 gyroscope is only ±300 °/s, suitable for low-speed high-precision attitude;The core differentiation of SCH16T-K10 is the ultra-large angular velocity range, specifically designed for high-speed rotation scenarios, with a range increase of nearly 7 times, at the cost of a slight increase in gyro noise compared to K01 Murata Man...。

4. Interface, data output, and synchronization capabilities

Communication interface: SafeSPI 2.0, 3.3V level, different from ordinary SPI, with communication error detection, reliability is higher in industrial strong interference environment.

Output mode: interpolation and extraction are supported, and the output rate can be flexibly configured; Supports 16-bit and 20-bit output, choose 16-bit for high-speed scenes, and choose 20-bit for high-precision recording.

Synchronization function

SYNC external synchronization input: external pulse trigger multi-sensor synchronous sampling;

DRDY data ready signal: new data ready output pulse, MCU can interrupt reading;

Hardware timestamp: mark the sampling time, eliminate time offset in multi-sensor fusion, and improve attitude calculation accuracy Murata Man...。

V. Self-diagnosis and protection mechanism

SCH16T-K10 inherits the full self-diagnosis system of Murata Industry's sensors:

MEMS core mechanical structure self-check, detect whether the sensing unit is damaged;

Power supply voltage monitoring, voltage abnormal marking fault;

Signal pathway, register reading and writing verification;

Over-range detection: if the angular velocity or acceleration exceeds the range, the hardware will mark the overflow state to avoid incorrect attitude output;

Temperature anomaly monitoring.

The entire self-checking logic allows the system to recognize sensor failure, avoid equipment misoperation based on incorrect attitude data, and is crucial for the safety control of drones and robots.

VI. Main application areas

SCH16T-K10 is designed for high-dynamic motion conditions, suitable for equipment with high rotational speed and large overload:

1. High-performance drones (core scenarios)

Racing drones, mobile multi-rotor, the body of the aircraft flips at high speed during flight, the ordinary IMU gyroscope is easy to saturate, the large gyroscope range of SCH16T-K10 will not saturate at high speed maneuvering, ensuring the reliable calculation of flight control attitude.

2. Special robots

High-speed motion robot, foot robot, rotating gimbal, high-speed motion robot arm, to cope with rapid steering and violent shaking conditions.

3. Construction machinery and special vehicles

Construction machinery posture monitoring, special vehicle inertial navigation, heavy equipment posture recording, adapt to outdoor vibration, wide temperature environment.

4. Sports monitoring, test and measurement equipment

High-speed rotating equipment attitude recording, dynamic motion test instrument, motion capture system.

5. INS (Inertial Navigation System)

And GPS / Beidou combination to build a combination navigation system for high-speed moving carriers.

VII. Core advantages of the product

The ultra-large gyro dynamic range, ±2000 ° / s, solves the gyro saturation failure problem under high-speed rotation conditions, and is the unique high-range version of the SCH16T series.

The factory's inter-axial orthogonal compensation reduces the calibration process on the production line and lowers the cost of mass production.

-40 ~ + 110 ℃ super wide temperature, suitable for vehicle, outdoor, closed high temperature equipment.

SafeSPI + hardware synchronization + timestamp, suitable for multi-sensor synchronous acquisition, convenient for IMU + GNSS combination navigation development.

Comprehensive hardware self-diagnosis, proactive reporting of faults, and improving the overall safety level.

MEMS mechanical reinforcement design, built-in vibration suppression algorithm, output stable in continuous vibration environment.

VIII. Selection Reference: Suitable and Inappropriate Scenarios

✅Scene selection is prioritized.

The equipment will undergo high-speed rotation and large angular velocity motion, and the ordinary IMU range is insufficient, which is easy to saturate;

Industrial-grade wide temperature range is required, and the equipment works in a vibration and impact environment for a long time;

Multiple sensors need to be synchronized to collect data and perform combined navigation attitude calculation;

The product has requirements for sensor fault recognition and safety monitoring.
