The IRA‑S200ST01 is an IRA‑S series economical TO‑5 package pyroelectric (PIR) passive infrared sensor launched by Murata, Japan. Relying on Murata's mature piezoelectric ceramic sensing material and mixed-signal IC process, it focuses on human body movement detection and indoor security sensing, and is an infrared component with extremely high versatility in consumer-level sensing devices.

The sensor works based on the pyroelectric effect of the pyroelectric ceramic crystal: the human body emits 10μm long-wave infrared radiation; When the moving human body enters the sensing area, the infrared heat received by the chip changes, and a weak voltage signal will be generated at both ends of the ceramic crystal to identify the moving object.

The built-in optical filter can filter out visible light and sunlight interference, allowing only human wavelength infrared light to pass through, thereby avoiding the problem of false triggering caused by light and sunlight.

1. Human body motion detection, only detects moving heat sources, stationary human body will not trigger output, suitable for waking up devices;

2. High signal-to-noise ratio (S/N) performance, weak human body movements can also generate effective analog signals;

3. Wide voltage adapter, low voltage 2V can start, suitable for battery-powered low-power products;

4. The metal TO-5 shell isolates external electromagnetic interference, and the anti-interference ability of the sensor in the environment of household appliances and strong electricity is better than that of the plastic shell.

Common usage scenarios

. Smart home lighting automation

Human body sensor night lamp, corridor sensor lamp, entrance hall sensor light source, wardrobe sensor lighting lamp; Depending on the 2V low-voltage characteristics, it can be made into a rechargeable inductive lamp.

 2. Security intrusion detection equipment

Indoor anti-theft alarm, door and window human sensing probe, shop counter detection sensor, home security main body sensing probe, are the commonly used components of early home infrared alarm.

 3. Small household appliances and consumer electronics

Smart trash can, automatic sensor faucet, human wake-up aromatherapy machine, sensor doorbell, sensor light in front of the mirror;

4. Commercial indoor equipment

Public toilet sensor equipment, automatic vending machine human wake-up, elevator cabin human presence detection, exhibition hall exhibit human sensing trigger device pim.murata...。

Unsuitable scenarios: harsh vehicle environment, medical high-precision equipment, outdoor open detection, industrial high-temperature equipment detection, Murata does not recommend using this sensor in the above scenarios.

Manufacturer: Murata

Product type: Plate machine interface mobile sensor and position sensor

RoHS:

Product: Motion Sensors

Output type: Analog

Power supply voltage - minimum: 2 V

Power supply voltage - maximum: 15 V

Maximum operating temperature: + 70 C

Minimum operating temperature: -40 C

Installation style: Through Hole

Measurement instrument: Motion

Technique: Long Pass

Packaging: Bulk

Trademark: Murata Electronics

Features: Excellent Sensitivity

Product Type: Board Mount Motion and Position Sensors

Series: IRA-S

100

Subcategory: Sensors

Part number alias: IML-0685

Unit weight: 3 g
