TDK-Lambda HWS600-24 Enclosed Single-output AC-DC Industrial Switching Power Supply

Core Key Parameters

1. Input Specifications

Single-phase AC input: 85～265VAC universal wide voltage range, 47~63HzCompatible DC input: 120～330VDCBuilt-in active PFC (Power Factor Correction), harmonic suppression complies with IEC61000-3-2 standardControlled inrush current during cold start, excellent power grid compatibility

2. Core Output Specifications

Rated output: 24V DC / 27A, rated power 600WMaximum continuous output power: 648WShort-term peak surge current: 31A to handle high inrush current at motor startupAdjustable output voltage range: 19.2V ~ 28.8V DC (±20% wide adjustment range)Typical overall conversion efficiency: 85%

III. Application Scope

1. UAV Industry

Power supply for ground control systems of medium and small inspection / aerial photography UAVsCentralized 24V power supply for ground consoles, small on-board Advantech industrial computers, video transmission modules and monitors.

Power supply for UAV production line test fixturesUsed for aging tests of UAV BMS battery protection boards and durability tests of low-power motors.

Power supply for simplified UAV charging cabinets and compact central control boxes for UAV cluster dispatching.

2. Industrial Automation Equipment

Power supply for small servo / stepper motor drivers and control cabinets of mini AGV automated guided vehiclesPower supply for machine vision cameras, assembly line detection sensors and compact PLC control systemsMain 24V power supply for automated test jigs and non-standard automated equipment

3. Energy Storage & Lithium Battery Equipment

Small lithium battery PACK assembly equipment and battery charge-discharge aging testersInternal power supply for portable low-power outdoor energy storage power stations and 24V small DC charging pile modules
