The CUS200M is a 200 W medical‑ and ITE‑certified AC‑DC switching power supply launched by TDK‑Lambda.

CUS200M is a 200 W medical‑ and ITE‑certified AC‑DC switching power supply from TDK‑Lambda. It belongs to the CUS‑M series and features an ultra‑slim convection‑cooled design, widely deployed in medical and industrial low‑noise applications.

Functions

Converts AC input to regulated DC output: accepts 85‑265 VAC input and provides standard output voltages including 12/18/24/48 VDC.200 W rating under convection cooling; up to 250 W with forced‑air cooling; fan‑less operation for low noise.High efficiency (up to 94 %); standby power consumption < 0.5 W for energy‑saving performance.Built‑in 5 V / 0.6 A standby power supply with Remote On/Off control.Medical‑grade safety: certified to IEC 60601‑1 (2×MOPP) and IEC 62368‑1; leakage current < 0.3 mA.

Typical Application Scope

Medical Equipment (Primary Target)Hospital monitors, ultrasound devices, ECG machines, dental equipment, portable medical instruments.Medical applications requiring low leakage current, high isolation and quiet operation.

ITE & IndustrialBroadcast / professional audio equipment, test‑and‑measurement instruments, laboratory apparatus.Industrial control, automation equipment, and electronic systems with low‑noise requirements.

Environmental & Mechanical Installation

Dimensions: 76.2 × 127 × 34 mm (3” × 5” × 1.3”), ultra‑slim for easy integration.Operating temperature: −20℃ ~ +70℃; maximum altitude 5000 m.Suitable for space‑constrained, fan‑less and high‑reliability power‑supply scenarios.

One‑sentence Summary

The CUS200M is a 200 W ultra‑slim, high‑efficiency and low‑noise universal power supply for medical and industrial use, delivering safe and stable power mainly for medical devices and quiet‑operation industrial applications.
