IRA-S210ST01 | Murata Thermopile PIR Human Infrared Sensor
| Item | Parameter |
|---|---|
| Operating Voltage | 2 V ~ 15 V DC |
| Output Type | Analog Voltage Output |
| Field of View (FOV) | 45° Horizontal / Vertical |
| Typical Sensitivity | 4.6 mV |
| IR Filter Window | 5 μm long-pass (matched to human 10 μm infrared radiation) |
| Operating Temperature | -40℃ ~ +70℃ |
| Storage Temperature | -40℃ ~ +85℃ |
| Mounting Type | Through Hole |
| Package Dimension | TO-5 metal can, height: 4.7 mm |
| Compliance | RoHS Compliant |
It cannot measure temperature and only detects moving heat sources (human motion). Stationary human bodies cannot be detected. Normally it must be used with Fresnel lens (common model: IML-0685 / IML-0688) and signal amplification circuit.
Recommended Applications:
Indoor human sensor lights, smart lighting
Indoor anti-intrusion alarm systems, security detectors
Human presence sensing for smart home (automatic sockets, automatic curtains)
Human motion sensing for office equipment, automatic small home appliances
Corridor sensor lamps, indoor sensor switches
