TDK-Lambda HWS Series 300W Single Output AC-DC Industrial Power Supply

24V output. Industrial-grade wide voltage input, high stability, fan-cooled. Designed for centralized power supply in automation systems and equipment cabinets.

II. Key Electrical Specifications

1. Input Specifications

AC Input: 85～265VAC (Universal wide-range voltage for global use)DC Compatible Input: 120～330VDCSingle-phase input, built-in EMI filter, Class B EMC complianceTypical Efficiency: 85%

2. Output Specifications (Core Parameters)

Rated Output Voltage: 24VDCAdjustable Range: 19.2～28.8VDC (±20% adjustable)Rated Current: 14APeak Current: 16.5ARated Power: 300W; Maximum peak power: 336WRemote Sense supported to compensate voltage drop on long cablesOptional PV model: External remote voltage adjustment via 0–10V / 4–20mA signal

III. Application Scope

1. Industrial Automation (Primary Application)

Central power supply for PLC control cabinets, auxiliary power of servo drives, solenoid valves, relays, cylinder actuators, control circuits of inverters and production line actuators.

2. Precision Equipment & Semiconductor Equipment

CNC machine tools, industrial robots, vibration monitoring sensors (e.g., 42688 accelerometers), wafer inspection equipment, test fixtures and centralized power supply for on-line monitoring instruments.

3. Detection & Measurement Control Systems

Power supply for vibration acquisition modules, data acquisition cards, 24V transmitters, industrial cameras and sensor assemblies.

1.HWS150A-24/A

2.HWS300-24

3.HWS600-24

4.HWS1500-24
