SPC584B70E3EHC0X, STMicroelectronics AEC-Q100 Automotive Grade 32-bit MCU

Operating Frequency: Up to 120 MHz

Memory (All embedded with ECC for memory error protection)Flash: 2048 KB (2 MB) Program FlashDataFlash: 64 KB (Can be emulated as EEPROM)SRAM: 128 KB General-purpose SRAM + 64 KB Core Local RAMHSM Dedicated Flash: 176 KB (Independent storage space for Hardware Security Module)

Package: 100-eTQFP (14×14 mm, SMD package with exposed pad), 88 GPIOs

Power Supply: Core 1.14 V ~ 1.26 V; IOs 3.0 V ~ 5.5 V (Typical 3.3 V)

Temperature Grade: -40 ℃ ~ +105 ℃, AEC-Q100 Grade1 Automotive Grade

III. Application Scope

1) Primary Automotive Applications

Automotive central gateway, body domain controller, door / seat / lighting control, on-board HVAC controller, auxiliary on-board charging control, commercial vehicle vehicle control unit

2) Applications for Automation Customers (Non-automotive projects requiring automotive-grade reliability)

Controllers for assist manipulators, folding jib cranes and gantry cranesEquipment safety monitoring, multi-sensor acquisition, multi-bus networking, firmware encryption and anti-tampering

Main control / gateway boards for RGV vehicles, AGVs and transfer machines

3) Other High-end Industrial Applications

ECUs for construction machinery, high-end test equipment, outdoor high-reliability industrial control equipment, slave control units for energy storage systems
