STMicroelectronics (ST) 6-axis digital Inertial Measurement Unit (IMU), integrating a 3-axis accelerometer and a 3-axis gyroscope

1. Measurement Ranges (Programmable Selectable)3-axis Accelerometer: ±2g / ±4g / ±8g / ±16g3-axis Gyroscope: ±125 / 250 / 500 / 1000 / 2000 dps (angular rate)Data Output: 16-bit high-precision ADC, maximum output data rate up to 6.66kHz

2. Power Supply & Power ConsumptionAnalog Supply VDD: 1.71V ~ 3.6VIndependent IO Supply VDDIO: Minimum 1.62V, compatible with low-voltage MCUsTypical current in high-performance mode with all 6 axes enabled: 0.55mA; Supports Always-On low-power mode for long standby operation of battery-powered devices

III. Application Fields by Industry

1. Consumer Electronics (Primary Applications)Smartphones & Tablets: Auto portrait/landscape switching, tap-to-wake, camera EIS (Electronic Image Stabilization) + OIS (Optical Image Stabilization), free-fall protectionSmartwatches / Fitness Bands / TWS Earbuds: All-day step counting, sleep monitoring, lift-to-wake, motion posture recognition, fall detection alarmGame Controllers, Motion Remote Controllers, Air Mice: 6-axis motion control and gesture recognition

2. Imaging, Aerial & Gimbal EquipmentImage stabilization for action cameras and dashcamsAttitude stabilization for micro drones and handheld gimbalsAttitude detection for mini aerial flight controllers with anti-vibration and low drift performance

3. AR/VR & Wearable Smart DevicesHead tracking and gesture capture for AR/VR glasses; portable motion interactive devices

ST意法半导体常用型号：

LIS2DWLTR

LSM6DSV16XTR

LSM6DSV32XTR

L9663-TR-1

L9369-TR

LSM6DSOETR3

LSM6DSK320XTR

ISM330DHCXTR

ASM330LHHTR

SPC584B70E3EHC0X

STM32H563MIY3QTR

STM32F0316DIE1

STM32G473VCT6

STM32H7B0ZBT6

STM32L053R8T6
