TPD6F002DSVR | Texas Instruments 6-Channel Pi-Type RC Low-Pass EMI Filter + ESD Protection Array

One-sentence summary

Integrated device providing EMI filtering and ESD surge protection for 6 signal channels. Consumer-grade (non-automotive), compact WFDFN12 package, used for noise reduction and ESD protection on high-speed data lines.

✅ Key Specifications

Brand: Texas Instruments (TI)

Model suffix DSVR: DSV package; R = tape-and-reel packaging

Number of channels: 6 channels, Pi-type 2nd-order RC low-pass filter, R=100Ω and C=17pF per channel

-3dB bandwidth: 100 MHz

Maximum signal voltage: 5.5 V (maximum voltage for signal lines)

ESD rating IEC61000-4-2: ±20 kV contact discharge, ±30 kV air discharge

Package: 12-pin WFDFN (SON), dimensions 3.0 × 1.35 mm, with exposed pad

Operating temperature: -40℃ ~ +85℃ (consumer-grade, non-AEC-Q100)

Leakage current: Low leakage, no interference with weak signals

Structure: Each channel integrates Pi-type RC filter and TVS ESD protection diode
