ST STM32G070KBT6 packaged LQFP32 microcontroller MCU

STM32G070KBT6 is a 32-bit microcontroller launched by STMicroelectronics, belonging to the STM32G070 mainstream value series. It uses ARM Cortex-M0+core and is suitable for consumer, industrial, and home appliance applications.

What is the core configuration of this chip

Core and Frequency: Equipped with Arm Cortex-M0+32-bit RISC core, the maximum operating frequency is 64 MHz.

Storage resources: Built in 128 KB Flash program memory and 36 KB SRAM data memory, with 32 KB SRAM supporting hardware parity check.

Packaging form: LQFP-32 packaging is used, with dimensions of 7.00 x 7.00 mm and a height of 1.40 mm, providing 29 available I/O ports.

Working voltage and temperature: The working voltage range is 2.0 V to 3.6 V, and the working temperature range is -40 ° C to 85 ° C, which is an industrial grade temperature standard. ‌‌‌

Typical Applications

Small appliances, power boards, sensor acquisition, LED control, relay drivers, simple CAN/serial devices, consumer electronics, low-cost industrial IO modules.
