B43700-E8688-M600 | EPCOS (TDK Group) | Screw-Terminal Polarized Aluminum Electrolytic Capacitor

## Key Specifications

- Rated Capacitance: 6800μF, tolerance ±20% (20℃, 120Hz)

- Rated DC Voltage: 600V DC; Max. surge voltage 660V DC

- Rated Ripple Current: 27.3A @ 100Hz, 85℃; Max. allowable ripple current 45.4A @ 100Hz, 60℃

- ESR (Equivalent Series Resistance): Typical 14mΩ (100Hz, 20℃)

- Package Dimension: Φ90mm × 197mm, M6 screw terminals, terminal spacing 31.7mm

- Temperature Range: -40℃ ~ +85℃

- Service Life: 8,000 hours under rated condition at 85℃

- Leakage Current: Typical 8300μA (600V, 20℃, after 5 minutes)

- Dissipation Factor tanδ: ≤0.2 (120Hz, 20℃)

- Construction: Aluminum can with black PET sleeve, **polarized capacitor**

- Packaging: Individual box packing

Main Features

1. High-power bus energy storage and filtering: Absorbs voltage spikes, smoothes DC voltage and suppresses power ripple on high-voltage DC bus.

2. Absorbs power-on inrush current, buffers sudden load changes, stabilizes bus voltage and protects downstream power devices (ESCs, IGBTs, power MOSFETs).

3. High ripple current handling capability and low ESR with low heat generation, suitable for long-duration high-current operation.

4. M6 screw terminals: Screw fastening for high-current wiring with reliable contact, designed for high-power chassis mounting.

5. Built-in safety vent: Releases pressure when internal pressure becomes excessive to improve safety.

6. Wide operating temperature range, suitable for harsh industrial environments.

 Applications

 High-Power Drones & Robots (Key Target Customers)

Energy storage and filtering for power bus and high-power ESCs of large multi-rotor drones

DC bus filtering for large AGVs and high-power servo drives

 Industrial Power Supplies & Converters

High-power industrial inverters, frequency converters, UPS (Uninterruptible Power Supply)

High-power welding machines, PV inverters and energy storage converters

High-Voltage Acquisition Equipment

Bus voltage stabilization and filtering for high-power test instruments and high-voltage power supplies
