ADM3101EACPZ‑REEL, Analog Devices (ADI), Single‑Channel RS‑232 Transceiver (Driver / Receiver)

Parameter Specification

Package 12‑LFCSP‑WQFN (3×3 mm, exposed pad)

Supply Voltage 3V ~ 5.5V (Typical 3.3V)

Driver / Receiver 1 Transmitter (Tx) / 1 Receiver (Rx), Full‑duplex

Maximum Data Rate 460 kbps

Quiescent Current 2.6 mA (Typical, no load)

ESD Protection ±8 kV contact discharge; ±15 kV air discharge (all I/O pins)

Receiver Hysteresis 400 mV for noise immunity

External Components 4 × 0.1 μF charge‑pump capacitors

Operating Temperature ‑40℃ ~ +85℃ (Industrial grade, non‑automotive)

Compliance Standards EIA/TIA‑232E, ITU‑T V.28

Typical Application Scenarios

‑ Industrial Control: PLC debug ports, RS232 communication ports for industrial modules, sensor serial‑data interaction‑ Instrumentation: Portable measuring equipment, portable medical devices, RS‑232 interfaces for battery‑powered meters‑ Communication Equipment: Console debug ports for switches and routers, equipment diagnostic ports‑ Security & POS Terminals: External serial‑port data interfaces‑ Embedded Systems: 3.3 V MCUs such as STM32 interfacing with legacy RS‑232 peripherals‑ Drones & Robots: Equipment debug serial ports, ground‑side debugging interfaces
