The BMI260 is an ultra-low power IMU that combines precise acceleration and angular rate measurements with intelligent on-chip motion-triggered interrupts.This 6-axis sensor integrates a 16-bit three-axis gyroscope and a 16- bit three-axis accelerometer into a compact 2.5×3 inch (16-bit) chip

Product Catalog Posture Sensor / Gyroscope

Accelerometer axis X, Y, Z

Acceleration measurement range (MAX) ±16g

Gyroscope axis X, Y, Z

Gyroscope range (MAX) ±2000 dps

Sensor type IMU (accelerometer + gyroscope)

Output number of bits 16bit

Attribute Parameter Value

Interface type I2C; SPI

Operating voltage 1.7V~ 3.6V

Cache size -

Idle current -

Operating temperature -40℃~+ 85℃

Functional characteristics Motion event detection; Synchronization and timestamps

BMI260 | German Bosch-Sensortec (Bosch) | Next-generation six-axis MEMS inertial measurement unit, integrated three-axis accelerometer + three-axis gyroscope, high precision, gyroscope self-calibration, low power consumption, is the mainstream motion attitude sensor in consumer electronics.

2. Core performance parameters

1. Sensing accuracy: dual 16-bit data output; The accelerometer resolution is 0.06mg / LSB, and the gyroscope can reach 0.004 dps / LSB, with extremely high detection sensitivity.

2. Programmable range

◦ Acceleration: adjustable from ±2g to ±16g

◦ Gyroscope: ±125dPS-±2000 dPS, suitable for slight attitude and high-speed rotation detection

3.Self-developed CRT gyroscope self-calibration: automatically compensates for offset after welding, sensitivity error control ± 0.4%, avoids data drift caused by soldering, stability targets automotive gyroscope process

4.Excellent temperature resistance: ‑40 ℃ ~ + 85 ℃ wide temperature operation, low temperature drift value, stable data in high and low temperature environment

5. Ultra-low power consumption: multi-step power-saving mode to prolong the battery life of portable devices.

6. Hardware interface: I2C, dual-channel SPI, built-in independent OIS anti-shake interface;Package LGA-14 (2.5 × 3.0mm), compact size suitable for small device PCB layout

III. Main functions

1. Posture motion acquisition: real-time reading of equipment tilt, rotation, vibration, movement acceleration, angular velocity

2. Lens stabilization OIS / EIS: independent stabilization channel, provides motion data for the camera, realizes optical stabilization and electronic video stabilization

3. Motion event recognition: step counting, hand-raising wake-up, flip detection, fall monitoring, gesture sensing

4. Indoor positioning PDR pedestrian trajectory calculation: no GPS environment relying on inertial data to complete indoor navigation and positioning

5. Interrupt Trigger: Vibration, tilt, and standstill can trigger chip interrupts, the master controller wakes up as needed, and reduces the overall power consumption.

6. Multi-sensor timestamp synchronization, can be used to build a nine-axis attitude module with an external magnetic sensor

IV. Core Uses

In short, it is to capture the movement of the equipment and sense the spatial attitude.

· Real-time tracking of equipment space angle, shaking, and vibration

· Camera image stabilization to counteract hand shake

· Identify user actions, steps, flips, and hand gestures

· Indoor inertial navigation, AR device spatial positioning

· Equipment vibration monitoring, vibration switch, hibernation wake-up control

V. List of landing product applications

1. Mobile phone imaging (main scenario)

Smartphone main camera stabilization module, front camera stabilization, many Android models are equipped with IMU stabilization chip

2. Intelligent wearable devices

Smartwatches, wristbands, Bluetooth earbuds, fitness wristbands: step counting, sleep monitoring, screen on by lifting wrist, motion gesture recognition

3. AR-VR smart glasses

Head posture tracking, spatial positioning, motion sensing, screen follow-up rotation

4. Portable digital

Sports camera, handheld gimbal, selfie stick, tablet, game controller body control

5. Smart Home & Small Appliances

Eye massage device, handheld beauty device, body sense remote control, human body sensing device

6. Industrial Internet of Things devices

Portable detector, handheld scanning device, vibration sensor, equipment attitude monitoring module
