CUS200M is a 200W AC-DC switching power supply from TDK-Lambda, certified for Medical and ITE applications.

Converts alternating current into stabilized direct current. Input range: 85–265 VAC; standard output voltages include 12/18/24/48 VDC.200 W output with natural convection cooling; up to 250 W under forced air cooling. Fanless design ensures low noise operation.High efficiency (up to 94%); standby power consumption <0.5 W for energy saving.Built-in 5 V / 0.6 A standby power supply, supporting Remote On/Off control.Medical-grade safety: certified to IEC 60601‑1 (2×MOPP) and IEC 62368‑1; leakage current <0.3 mA.

Applications

Medical Equipment (Primary Target)

Hospital patient monitors, ultrasound equipment, ECG machines, dental equipment, portable medical instruments.Suitable for medical scenarios requiring low leakage current, high isolation and silent operation.

ITE & Industrial Fields

Broadcast / professional audio equipment, test & measurement instruments, laboratory devices.Industrial controls, automation equipment, and electronic systems with low-noise requirements.

Environment & Mounting

Dimensions: 76.2 × 127 × 34 mm (3” × 5” × 1.3”). Ultra-slim form factor for easy integration.Operating temperature: −20°C ~ +70°C; maximum operating altitude: 5000 m.Ideal for space-constrained, fanless and high-reliability power supply applications.

Summary

The CUS200M is a 200 W ultra-slim, high-efficiency and low-noise universal power supply for medical and industrial use. It delivers safe and stable power, primarily for medical devices and silent industrial applications.
