GRM2195C1H103JA01D, Murata, Surface-mount Multilayer Ceramic Capacitor (MLCC)

Key Parameters

• Capacitance: 10nF (0.01μF)

• Tolerance: ±5% (J code)

• Rated Voltage: 50V DC

• Dielectric: C0G (NP0) – excellent temperature stability & low dissipation factor

• Package: 0805 (2.0×1.25mm)

• Operating Temperature Range: -55℃ ~ +125℃

Core Function

For filtering, coupling, bypassing, oscillator frequency stabilization and signal matching in high-frequency & precision circuits. C0G dielectric is ideal for applications requiring stable capacitance, low loss and negligible capacitance drift against temperature change.

Detailed Applications

• Power supply filtering & decoupling: Eliminate high-frequency interference, stabilize supply voltage and reduce noise.

• Signal coupling & DC blocking: Pass AC signals while blocking DC voltage for inter-stage impedance matching.

• Oscillator & clock circuits: Work with crystal oscillators to fix operating frequency for MCU clock.

• RF & wireless circuitry: RF filtering, impedance matching and signal coupling.

• Precision sampling & ADC front-end: Ultra-low temperature drift of C0G guarantees high sampling accuracy.

• Audio circuits: Signal coupling and noise filtering for clear sound performance.

Application Fields

Consumer Electronics

Smart speakers, Bluetooth earbuds & TWS, tablets, game consoles, set-top boxes, remote controllers and small home appliance control boards.

Communication & RF

Wi‑Fi/Bluetooth modules, NB‑IoT/4G/5G modules, RF transceivers, antenna matching circuits, routers, ONUs and switches.

Industrial & IoT

Temperature/humidity/pressure/vibration sensor nodes, measuring instruments, PLC, industrial control boards and low-leakage battery-powered devices.

Automotive Electronics (Non-safety relevant circuits)

Car navigation, dashcams, in-car infotainment, auxiliary BMS circuits, vehicle lamps and body control modules.

Summary for Customer & Social Media

GRM2195C1H103JA01D from Murata is a high-precision 0805 MLCC with 10nF, 50V and C0G dielectric. It features ultra-low temperature drift and low loss for high-frequency filtering, signal coupling, clock stabilization and precision sampling, widely used in consumer electronics, communication, industrial IoT and automotive electronics.
